Multibeam module for LED Glare Free High Beam English

  • Category Technical paper
  • Edition SIA
  • Date 10/14/2014
  • Author Damien CABANNE, José HERRERA, Jesús ROMO - Valeo
  • Language English
  • Type PDF file (693.85 Ko)
    (Downloadable immediately on receipt of online payment)
  • Number of pages 6
  • Code R-2014-03-05
  • Fee from 8.00 € to 10.00 €

Among the different LED Glare Free solutions, the multibeam module is allowing a range of beam possibilities, from low beam to motorway light, progressive high beam and glare free, with the advantage of combining the proven technology of rotative drum with stepper motor with a reduced number of led. The module described in this paper corresponds to this functionality, in a compact design, allowing many possibilities for integration and design. With its high performances, it contributes to the major part of the low beam, high beam and selective beam, while the specific design of the light shield generates the different beam patterns in a progressive way for driver comfort. Outstandingly, those features are achieved in spite of a very limited height of output lens. It is designed to be proposed as a standard module, style differentiation being made by addition of bezels. In this configuration, it can be integrated into many different vehicles configurations. After the description of the module features, the performances of a first application into serial headlamp are presented.

Order

Conference proceedings and magazines are sent by post contrary to the PDF files, which can be downloaded as soon as the payment is completed.
They can't be ordered in the same shopping cart.

Select your fee
